Video Overview
Professional Step-by-Step Installation Tutorial by Senior Engineers
This comprehensive installation guide demonstrates the complete setup process for the TW Series Oil-Free Screw Compressor, from initial unboxing through final commissioning. Our senior engineer with 15 years of experience walks you through every critical step.
What You’ll Learn:
- Proper unboxing procedures and equipment inspection checklist
- Foundation requirements and spatial clearance specifications
- Electrical connections and grounding standards
- Piping installation best practices and sealing techniques
- Initial startup sequence and commissioning procedures
- Common installation mistakes and how to avoid them
Important Note:
While this video provides detailed guidance, we strongly recommend having our technical engineers on-site for first-time installations to ensure optimal equipment performance and safety compliance.
Video duration: 18 minutes. Best viewed alongside the TW Series Installation Manual for complete reference.
Key Features
Comprehensive safety protocols and precautions explained
Electrical wiring diagram with on-site demonstration
Correct vs. incorrect piping connection examples shown
Complete startup checklist for first-time commissioning
Optimal parameter settings and best practices
On-site troubleshooting methods for common issues
Technical Specifications
Detailed parameters and specifications
| Parameter | Value |
|---|---|
| Applicable Models | TW-100 to TW-500 Full Series |
| Required Installation Space | Equipment perimeter ≥ 1.5m clearance |
| Foundation Load Capacity | 800-2000 kg/m² depending on model |
| Power Supply Specification | 380V / 50Hz Three-phase Four-wire |
| Inlet Pipe Diameter | DN80 - DN150 |
| Ambient Temperature Range | 0°C - 45°C |
| Estimated Installation Time | 2-4 hours (excluding foundation work) |
Frequently Asked Questions
Everything you need to know
Can we install the equipment ourselves without professional technicians?
Yes, but certain conditions must be met: 1. At least 2 personnel with valid electrician certifications 2. Basic mechanical installation experience 3. Strict adherence to video instructions and manual procedures 4. We recommend applying for our remote technical support (free of charge) for first-time installations For larger models (TW-300 and above), we strongly recommend having our engineers on-site to guide the installation, ensuring equipment performance and warranty validity.
What are the most common mistakes during installation?
Based on our statistics, the top 3 common errors are: 1. Electrical Wiring Issues (40% of cases) - Reversed phase sequence or improper grounding → Always use a phase sequence meter for verification; grounding resistance must be <4Ω 2. Piping Connection Problems (30% of cases) - Hoses too long or bending radius too small → Follow the "3D2L" principle shown in video (bending radius ≥3× pipe diameter, length ≤2 meters) 3. First Startup Oversights (20% of cases) - Failure to purge air or check oil level → Strictly follow the startup checklist item by item The video provides special annotations and detailed demonstrations for all these common error points.
How long does it take to reach rated performance after installation?
The TW Series has a very short break-in period: - Immediately after first startup: achieves 90% of rated performance - After 100 hours of operation: perform first maintenance (change initial oil) - After 500 hours: reaches 100% performance and enters stable operation period During the break-in period, we recommend: - First 50 hours: avoid full-load operation (maintain at 70-80% capacity) - Daily parameter logging to monitor abnormalities - Immediately stop operation if any unusual sounds or vibrations occur
Where can I download the installation tools checklist shown in the video?
The tools checklist and all supporting materials are available in the product page's "Download Center": - TW Series Installation Tools Checklist.pdf - Electrical Wiring Diagrams.dwg - Piping Layout Reference Drawings.pdf - First Startup Inspection Checklist.xlsx You can also find download links in the video description, or contact our technical support to have them sent directly to you.
